X500 Frame (CNC)

(1 customer review)

Original price was: $ 15.00.Current price is: $ 12.00.

  • All parts(.STL and PDF files) in one .ZIP file.
  • Easily printable on 220X220X250(mm) 3D printer.
  • Parts are easily assemblable i.e. with screws only.
  • STP files for CNC cutting.
  • Total printing Volume: 37,902 cubic mm.

License – TheMechNinja Paid Standard Digital File License

Categories: , , Tags: , ,
Guaranteed Safe Checkout
  • UPI ICON

CNC X500 Drone Frame CNC STP Files

This file contains all the files required to print your own X500 drone frame at home.

Total Printing Volume of all 14 Files: 37,902 mm³

This file contains 10 files i.e.

5 .STL files for 3D printing.

  1. 10mm pipe Holder.STL
  2. Bottom Plate Connector.STL
  3. Connector.STL
  4. Landing Gear Bottom Mount.STL
  5. Landing Gear Mount.STL

5 .STP files for CNC cutting.

  1. Back Plate.STP
  2. Bottom Plate.STP
  3. Middle Plate.STP
  4. Motor Plate.STP
  5. Top Plate.STP

The X500 drone frame is distributed into the above-mentioned parts so that you can easily print any part at your home with your own DIY 3D printer of minimal size i.e. 220(mm)x220(mm)x250(mm).

To make your own homemade 3D printer at home see the blog below.

Homemade 3D Printer | Simple DIY Under $150

All the files given are complete and have been tested.

The print volume of all files (approximately):-

  1. 10mm pipe Holder

    • Size – 10 x 25 x 19 (mm)
    • Volume – 2,928 mm³
  2. Bottom Plate Connector

    • Size – 10 x 84 x 44 (mm)
    • Volume – 9,958 mm³
  3. Connector

    • Size – 33 x 33 x 15 (mm)
    • Volume – 4,336 mm³
  4. Landing Gear Bottom Mount

    • Size – 34 x 34 x 49 (mm)
    • Volume – 11,152 mm³
  5. Landing Gear Mount

    • Size – 27 x 38 x 40 (mm)
    • Volume – 9,528 mm³

PDF files are also attached in the ZIP folder to make the installation easier.

1 review for X500 Frame (CNC)

    Gaurav
    June 23, 2021
    Wow perfect design I found out so far. Same problem with this design again. I have to find someone else for CNC. They should ship the CNC cut parts too.
